    CCTVPLANNER · DESIGN GALLERY

    Real CCTV plans. Real coverage.

    Eight reference layouts spanning warehouses, retail, parking, schools, and more. Every camera shown is a real model from our 65,000-SKU catalog, with field-of-view cones computed from real lens specs per EN 62676-4.

    EIGHT REFERENCE LAYOUTS · ALL VERTICALS

    Pick a layout closest to your project.

    Floor plan of a warehouse with 12 CCTV cameras placed at loading docks, aisles, and perimeter exits, designed with CCTVplanner
    Warehouse

    Warehouse · 12-camera coverage

    Twelve cameras covering loading docks, racking aisles, and the perimeter fence. Mix of 4 MP bullets at 6 m mount and 2 PTZs at the dock entry.

    12 cameras
    CCTV layout for a retail store with 8 cameras at checkouts, entrances, and stockroom, designed with CCTVplanner
    Retail

    Retail store · 8-camera point-of-sale plan

    Eight cameras anchored to checkouts, the front entrance, the stockroom door, and high-shrink aisles. Dome form factor for ceiling clearance.

    8 cameras
    Multi-floor office building CCTV plan with 16 cameras at lobbies, lifts, server room, and parking, designed with CCTVplanner
    Office

    Office building · 16-camera multi-floor plan

    Sixteen cameras across three floors: lobby, lift cores, server room, and the underground car park. ANPR camera at the gate.

    16 cameras
    Outdoor parking lot CCTV plan with 6 cameras covering entry barrier, driving lanes, and bay rows, designed with CCTVplanner
    Parking

    Parking lot · 6-camera ANPR + overview

    Six cameras combining ANPR at the barrier with overview at each bay row. IR-illuminated bullets for night driving lanes.

    6 cameras
    Residential apartment complex CCTV layout with 10 cameras at entrances, stairwells, post boxes, and bin store, designed with CCTVplanner
    Residential

    Apartment complex · 10-camera shared-area plan

    Ten cameras across two buildings: main and back entrances, stairwell cores, post boxes, bin store, and the bike room. GDPR-friendly angles.

    10 cameras
    School campus CCTV plan with 20 cameras covering main entrance, perimeter fence, corridors, cafeteria, and playgrounds, designed with CCTVplanner
    School

    School campus · 20-camera perimeter + interior plan

    Twenty cameras balancing safeguarding with privacy: main entrance, perimeter fence, corridors, cafeteria, playgrounds. Vandal-resistant domes inside.

    20 cameras
    Hotel property CCTV layout with 14 cameras at reception, corridors, car park, and back-of-house, designed with CCTVplanner
    Hospitality

    Hotel property · 14-camera lobby + corridors plan

    Fourteen cameras: reception, lifts, every corridor, the car park, and back-of-house corridors. Bullets for cost, domes for guest-facing areas.

    14 cameras
    Gas station CCTV layout with 7 cameras at forecourt pumps, shop interior, and car wash, designed with CCTVplanner
    Industrial

    Gas station · 7-camera forecourt + shop plan

    Seven cameras across the forecourt, shop, and car wash. ANPR at the entrance, IR bullets covering each pump island.

    7 cameras

    Design your own — free, in the browser.

    Upload your floor plan, drop cameras, and export a PDF in minutes. Works on desktop, tablet, and mobile.
